Structure and Working Principle

• Structure
  • Hanging Frame: It is used to connect with the mini tractor, playing the role of supporting and connecting the entire reversible plow.
  • Plow Body: The plow body is the component that directly performs operations such as turning and breaking the soil. It is usually made of high - carbon steel, which has high hardness and wear - resistance.
  • Reversible Mechanism: It is mainly composed of a hydraulic cylinder or a mechanical transmission device. The hydraulic - type reversible mechanism realizes the vertical flipping of the plow body through the extension and retraction of the piston rod in the hydraulic cylinder, while the mechanical - type one realizes the flipping of the plow body through mechanical linkages.
  • Depth - Limiting Wheel Mechanism: It is used to control the plowing depth of the plow body. Usually, the plowing depth can be adjusted by a screw rod. It can also play a supporting role during transportation to facilitate the movement of the plow.
• Working Principle: The reversible plow for a mini tractor is controlled by the tractor's hydraulic system. When plowing, the tractor's hydraulic system supplies oil to the hydraulic cylinder of the reversible plow, and the hydraulic cylinder drives the plow body to flip, so as to realize the alternate work of the forward and reverse plow bodies and complete the plowing operation.

Characteristics

• Suitable for Small - Scale Operations: It is designed for mini tractors, which are suitable for small - scale farms, vegetable gardens, orchards and other places. It has the characteristics of small size, flexibility and convenience, and can operate in limited spaces.
• High Work Efficiency: The reversible plow can alternately use the forward and reverse plow bodies to plow, which can double the work efficiency compared with the single - sided plow, and can complete the plowing task in a shorter time.
• Good Plowing Quality: It can turn over the soil deeply, break up large soil clods, and make the soil loose and flat, which is conducive to the growth of crops. At the same time, it can also bury crop residues and weeds, which is helpful to reduce the growth of weeds and the occurrence of pests and diseases.
• Adjustable Plowing Depth: The plowing depth of the reversible plow can be adjusted according to different soil conditions and farming requirements, generally ranging from 12 cm to 35 cm.
